Mühlbauer’s lamination system LP 5570/E is designed to laminate pre-lams, holderpages and similar products such as plastic cards, smartcards and contactless cards. The system complies with the latest demands regarding economics, eco-friendlyness, as well as product and process quality. All important process parameters such as temperature, pressure and cycle time are continuously and individually controlled. Thus, it is possible to laminate under optimal conditions with all current card materials such as ABS, PVC, PC, PET, PETG, PS, PE and PP. An available option is the weight compensation for the hot press, which allows for the lamination of plastic holderpages. The LP 5570/E can be configured with eight or ten openings and both systems are capable of holding between six and twelve layers per opening, depending on the production material.
